Dongying Kangdi Mechanical Equipment Co.,LTD with better price,reliable quality,professional service
9 Years
| Ask Lasest Price | |
| Brand Name : | new |
| Model Number : | new |
| Certification : | new |
| Price : | FOB 100000-200000USD |
| Supply Ability : | 10 set/month |
| Delivery Time : | 30 work days |
for more pls send saleskd2013@hotmail.com
Technical parameter
Drill depth(m)
150
Drill diameter(mm)
500-2500
Top head speed(r/min)
22
Top head torque(kN.m)
7.5
Total line pull force of minor winch(t)
18
Tower hight(mm)
6980
Bearing (t)
20
Drill pipe(mm)
Ф168×8×2000
6BS gravel pump
theoretical flow(m³/min)
200
Revolving speed(r/min)
750
Input power(kw)
30
CB—E532 vacuum pump
Max-displacement(L/min)
3400
Revolving speed(r/min)
1450
Input power((kw)
7.5
Engine
Diesel engine
model
YC6J180-33
Rated power(KW)
132
speed(r/min)
2500
torque
590N.m/1400-1700rpm
Drive form of chassis
4×2
Generator set
Rated power(kW)
100
Rated voltage (V)
400
frequency (Hz)
50
Walking speed(km/h)
75
Transport dimension (L×W×H)(mm)
9620*2480*3920
Working dimension (L×W×H)(mm)
8680*4560*8852
|
|
